FORTRA-RTFU Cable Gland

For all types of Armoured or Braided / Screened cables

Description

The TFU range of cable glands are for use in heavy duty applications in Explosive Atmospheres. For all types of Armoured or Braided / Screened cables. Designed with a unique adaptive cone and no loose components.

Features

  • Flameproof inner diaphragm seal – safe, reliable & robust; no installation or inspection ambiguity
  • Excellent cold flow performance with third party verified test report on cable types used globally
  • Unique patented captive ‘Adaptive’ armour cone for all types of armour or braid, with captive ‘AnyWay’ clamping ring
  • Metal-to-metal armour clamping; no installation or inspection ambiguity
  • Fewer installation steps for faster process. Unique ‘Quick’ thread for faster armour clamping
  • Outer seal with wider cable acceptance, meaning fewer stocking sizes
  • IP66, 67, 68, 69 & 69K as standard with fully enclosed/protected deluge seal for third party compliance to DTS 01
  • Compact design; ideal for applications with limited installation space
  • Fewer tools required for installation and maintenance

Additional Information

Certification
ATEX Certificate Number CML 24ATEX1333X
ATEX Certificate Number 2 CML 24ATEX4334X
ATEX Code of Protection ^ I M2 Ex db I Mb, Ex eb I Mb; ^ II 2G 3G 1D Ex db IIC Gb, Ex eb IIC Gb, Ex nR IIC Gc, Ex ta IIIC Da
ATEX Compliance Standards EN 60079-0, -1, -7, -15, -31
ATEX Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/b64a2a83/686e5ec24453089c533a212d/atexlogo.jpg
IECEx Certificate Number IECEx CML 24.0137X
IECEx Code of Protection Ex db I Mb, Ex eb I Mb, Ex db IIC Gb, Ex eb IIC Gb, Ex nR IIC Gc, Ex ta IIIC Da
IECEx Compliance Standards IEC 60079-0, -1, -7, -15, -31
IECEx Logo Filename iecexlogo.jpg
IECEx Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/68474635/686e5ec24453089c533a212e/iecexlogo.jpg
Industrial Certificate Number CML 24CA17921
CE Logo Filename CE.jpg
CE Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/8c592104/686e5ec24453089c533a212f/CE.jpg
Technical Specification
Application EXAT
Armour Clamping Captive ‘Adaptive’ Armour Cone and Captive ‘AnyWay’ Clamping Ring
Seal Material LSF Halogen Free Silicone
Seal Technique CMP Inner Diaphragm Seal and Outer Load Retention Seal
Seal Area(s) Cable Inner Bedding and Cable Outer Sheath
Type Material Options Brass, Nickel Plated Brass, Aluminium, Stainless Steel

* Mechanical classifications applied as per IEC/EN 62444
** When CMP installation accessories are used. Refer to www.cmp-products.com for further information
*** IP68 tested to 300 kPa for 168 hours (equivalent to 30 metres water depth)

Downloads

Certificates

Product Selector

1
Part Number Size Material Entry Thread Entry Thread Size TS Entry Thread Pitch TP Min Overall Cable Ø OS (mm) Max Overall Cable Ø OS (mm) Min Overall Cable Ø OS (Imp) Max Overall Cable Ø OS (Imp) Min Thread Length TL (mm) Min Thread Length TL (Imp) Max Across Flats AF (mm) Max Across Corners AC (mm) Max Across Flats AF (Imp) Max Across Corners AC (Imp) Max Protrusion Length PL (mm) Min Cable Bedding Ø IB (mm) Max Cable Bedding Ø IB (mm) Max Cable Bedding Ø IB (Imp) Min Cable Bedding Ø IB (Imp) Min Armour Thickness X Cone X1 (mm) Max Armour Thickness X Cone X1 (mm) Min Armour Thickness X Cone X1 (Imp) Min Armour Thickness W Cone W1 (mm) Max Armour Thickness W Cone W1 (mm) Min Armour Thickness W Cone W1 (Imp) Max Armour Thickness W Cone W1 (Imp) Shroud Size Ass'y Weight
20RTFU002 20 Brass Metric M20 1.5 12.5 20.9 0.49 0.82 15 0.59 30.5 33.6 1.2 1.32 69.8 8 14 0.31 0.55 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC06 0.22
20S16RTFU002 20S16 Brass Metric M20 1.5 6.1 13.2 0.24 0.52 15 0.59 24 26.4 0.94 1.04 71.5 3.1 7 0.12 0.28 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC36 0.14
20SRTFU002 20S Brass Metric M20 1.5 9.5 15.9 0.37 0.63 15 0.59 24 26.4 0.94 1.04 71.5 6 11.6 0.24 0.46 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC36 0.14
20SRTFU031 20S Brass NPT 1/2" 9.5 15.9 0.37 0.63 19.9 0.78 24 26.4 0.94 1.04 71.5 6 11.6 0.24 0.46 0.2 0.02 0.01 0.8 1.25 0.03 0.05 0.15
20RTFU031 20 Brass NPT 1/2" 12.5 20.9 0.49 0.82 19.9 0.78 30.5 33.6 1.2 1.32 69.8 8 14 0.31 0.55 0.2 0.02 0.01 0.8 1.25 0.03 0.05 0.23
20S16RTFU031 20S16 Brass NPT 1/2" 6.1 13.2 0.24 0.52 19.9 0.78 24 26.4 0.94 1.04 71.5 3.1 7 0.12 0.28 0.2 0.02 0.01 0.8 1.25 0.03 0.05 0.15
20RTFU402 20 Stainless Steel Metric M20 1.5 12.5 20.9 0.49 0.82 15 0.59 30.5 33.6 1.2 1.32 69.8 8 14 0.31 0.55 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC06 0.2
20S16RTFU402 20S16 Stainless Steel Metric M20 1.5 6.1 13.2 0.24 0.52 15 0.59 24 26.4 0.94 1.04 71.5 3.1 7 0.12 0.28 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC36 0.13
20SRTFU402 20S Stainless Steel Metric M20 1.5 9.5 15.9 0.37 0.63 15 0.59 24 26.4 0.94 1.04 71.5 6 11.6 0.24 0.46 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC36 0.12
20S16RTFU502 20S16 Nickel Plated Brass Metric M20 1.5 6.1 13.2 0.24 0.52 15 0.59 24 26.4 0.94 1.04 71.5 3.1 7 0.12 0.28 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC36 0.14
20SRTFU502 20S Nickel Plated Brass Metric M20 1.5 9.5 15.9 0.37 0.63 15 0.59 24 26.4 0.94 1.04 71.5 6 11.6 0.24 0.46 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC36 0.14
20RTFU502 20 Nickel Plated Brass Metric M20 1.5 12.5 20.9 0.49 0.82 15 0.59 30.5 33.6 1.2 1.32 69.8 8 14 0.31 0.55 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC06 0.22
25RTFU003 25 Brass Metric M25 1.5 16 26.2 0.63 1.03 15 0.59 37.5 41.3 1.48 1.63 81.1 11 19.5 0.43 0.77 0.2 0.02 0.01 1.3 1.6 0.05 0.06 PVC09 0.35
25RTFU032 25 Brass NPT 3/4" 16 26.2 0.63 1.03 20.2 0.8 37.5 41.3 1.48 1.63 81.1 11 19.5 0.43 0.77 0.2 0.02 0.01 1.3 1.6 0.05 0.06 0.36
25RTFU403 25 Stainless Steel Metric M25 1.5 16 26.2 0.63 1.03 15 0.59 37.5 41.3 1.48 1.63 81.1 11 19.5 0.43 0.77 0.2 0.02 0.01 1.3 1.6 0.05 0.06 PVC09 0.32
25RTFU503 25 Nickel Plated Brass Metric M25 1.5 16 26.2 0.63 1.03 15 0.59 37.5 41.3 1.48 1.63 81.1 11 19.5 0.43 0.77 0.2 0.02 0.01 1.3 1.6 0.05 0.06 PVC09 0.35
32RTFU004 32 Brass Metric M32 1.5 21.5 33.9 0.85 1.33 15 0.59 46 50.6 1.81 1.99 89.8 17 26.5 0.67 1.04 0.2 0.02 0.01 1.6 2 0.06 0.08 PVC11 0.54
32RTFU404 32 Stainless Steel Metric M32 1.5 21.5 33.9 0.85 1.33 15 0.59 46 50.6 1.81 1.99 89.8 17 26.5 0.67 1.04 0.2 0.02 0.01 1.6 2 0.06 0.08 PVC11 0.49
32RTFU504 32 Nickel Plated Brass Metric M32 1.5 21.5 33.9 0.85 1.33 15 0.59 46 50.6 1.81 1.99 89.8 17 26.5 0.67 1.04 0.2 0.02 0.01 1.6 2 0.06 0.08 PVC11 0.54
40RTFU005 40 Brass Metric M40 1.5 28 40.4 1.1 1.59 15 0.59 55 60.5 2.17 2.38 92.8 22 32 0.87 1.26 0.2 0.03 0.01 1.6 2 0.06 0.08 PVC15 0.76
40RTFU405 40 Stainless Steel Metric M40 1.5 28 40.4 1.1 1.59 15 0.59 55 60.5 2.17 2.38 92.8 22 32 0.87 1.26 0.2 0.03 0.01 1.6 2 0.06 0.08 PVC15 0.71
40RTFU505 40 Nickel Plated Brass Metric M40 1.5 28 40.4 1.1 1.59 15 0.59 55 60.5 2.17 2.38 92.8 22 32 0.87 1.26 0.2 0.03 0.01 1.6 2 0.06 0.08 PVC15 0.76
40RTFU534 40 Brass NPT 1-1/4" 28 40.4 1.1 1.59 25.6 1.01 55 60.5 2.17 2.38 92.8 22 32 0.87 1.26 0.2 0.03 0.01 1.6 2 0.06 0.08 0.81
50RTFU006 50 Brass Metric M50 1.5 38 53.2 1.5 2.09 15 0.59 70 77 2.76 3.03 101.3 29.5 44 1.16 1.73 0.3 0.03 0.01 2 2.5 0.08 0.1 PVC21 1.2
50RTFU406 50 Stainless Steel Metric M50 1.5 38 53.2 1.5 2.09 15 0.59 70 77 2.76 3.03 101.3 29.5 44 1.16 1.73 0.3 0.03 0.01 2 2.5 0.08 0.1 PVC21 1.11
50RTFU506 50 Nickel Plated Brass Metric M50 1.5 38 53.2 1.5 2.09 15 0.59 70 77 2.76 3.03 101.3 29.5 44 1.16 1.73 0.3 0.03 0.01 2 2.5 0.08 0.1 PVC21 1.2
63RTFU007 63 Brass Metric M63 1.5 52 66 2.05 2.6 15 0.59 80 88 3.15 3.46 112.9 41.5 55 1.63 2.17 0.3 0.03 0.01 2 2.5 0.08 0.1 PVC25 1.49
63RTFU407 63 Stainless Steel Metric M63 1.5 52 66 2.05 2.6 15 0.59 80 88 3.15 3.46 112.9 41.5 55 1.63 2.17 0.3 0.03 0.01 2 2.5 0.08 0.1 PVC25 1.38
63RTFU507 63 Nickel Plated Brass Metric M63 1.5 52 66 2.05 2.6 15 0.59 80 88 3.15 3.46 112.9 41.5 55 1.63 2.17 0.3 0.03 0.01 2 2.5 0.08 0.1 PVC25 1.49
75RTFU008 75 Brass Metric M75 1.5 64.5 78.5 2.54 3.09 15 0.59 100 110 3.94 4.33 112.4 53.5 68 2.11 2.68 0.3 0.03 0.01 2.5 3.15 0.1 0.12 PVC30 2.61
75RTFU408 75 Stainless Steel Metric M75 1.5 64.5 78.5 2.54 3.09 15 0.59 100 110 3.94 4.33 112.4 53.5 68 2.11 2.68 0.3 0.03 0.01 2.5 3.15 0.1 0.12 PVC30 2.41
75RTFU508 75 Nickel Plated Brass Metric M75 1.5 64.5 78.5 2.54 3.09 15 0.59 100 110 3.94 4.33 112.4 53.5 68 2.11 2.68 0.3 0.03 0.01 2.5 3.15 0.1 0.12 PVC30 2.61
90RTFU009 90 Brass Metric M90 2 75 90.5 2.95 3.56 24 0.94 114 125.4 4.49 4.94 150.3 66 78.5 2.6 3.09 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC32 4.91
90RTFU409 90 Stainless Steel Metric M90 2 75 90.5 2.95 3.56 24 0.94 114 125.4 4.49 4.94 150.3 66 78.5 2.6 3.09 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC32 4.52
90RTFU509 90 Nickel Plated Brass Metric M90 2 75 90.5 2.95 3.56 24 0.94 114 125.4 4.49 4.94 150.3 66 78.5 2.6 3.09 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC32 4.91
100RTFU0010 100 Brass Metric M100 2 86 101.5 3.39 4 24 0.94 123 135.3 4.84 5.33 160.2 76 90.5 2.99 3.56 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC33 5.22
100RTFU4010 100 Stainless Steel Metric M100 2 86 101.5 3.39 4 24 0.94 123 135.3 4.84 5.33 160.2 76 90.5 2.99 3.56 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC33 4.82
100RTFU5010 100 Nickel Plated Brass Metric M100 2 86 101.5 3.39 4 24 0.94 123 135.3 4.84 5.33 160.2 76 90.5 2.99 3.56 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC33 5.22
115RTFU0011 115 Brass Metric M115 2 101 110.5 3.98 4.35 24 0.94 133 146.3 5.24 5.76 180.7 86 98 3.39 3.86 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC34 7.25
115RTFU4011 115 Stainless Steel Metric M115 2 101 110.5 3.98 4.35 24 0.94 133 146.3 5.24 5.76 180.7 86 98 3.39 3.86 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC34 6.7
115RTFU5011 115 Nickel Plated Brass Metric M115 2 101 110.5 3.98 4.35 24 0.94 133 146.3 5.24 5.76 180.7 86 98 3.39 3.86 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC34 7.25
130RTFU0012 130 Brass Metric M130 2 110 123.5 4.33 4.8 24 0.94 153 168.3 6.02 6.6 191.5 97 115 3.82 4.53 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC35 9.47
130RTFU4012 130 Stainless Steel Metric M130 2 110 123.5 4.33 4.8 24 0.94 153 168.3 6.02 6.6 191.5 97 115 3.82 4.53 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC35 8.75
130RTFU5012 130 Nickel Plated Brass Metric M130 2 110 123.5 4.33 4.8 24 0.94 153 168.3 6.02 6.6 191.5 97 115 3.82 4.53 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC35 9.47
