FORTRA-TFU Cable Gland

ETIM Classification

EC000441

For all types of Armoured or Braided / Screened cables

Description

The TFU range of cable glands are for use in heavy duty applications in Explosive Atmospheres. For all types of Armoured or Braided / Screened cables. Designed with a unique adaptive cone and no loose components.

Features

  • Flameproof inner diaphragm seal – safe, reliable & robust; no installation or inspection ambiguity
  • Excellent cold flow performance with third party verified test report on cable types used globally
  • Unique patented captive ‘Adaptive’ armour cone for all types of armour or braid, with captive ‘AnyWay’ clamping ring
  • Metal-to-metal armour clamping; no installation or inspection ambiguity
  • Fewer installation steps for faster process. Unique ‘Quick’ thread for faster armour clamping
  • Outer seal with wider cable acceptance, meaning fewer stocking sizes
  • IP66, 67, 68, 69 & 69K as standard with fully enclosed/protected deluge seal for third party compliance to DTS 01
  • Compact design; ideal for applications with limited installation space
  • Fewer tools required for installation and maintenance

Additional Information

Certification
ATEX Certificate Number CML 24ATEX1333X
ATEX Certificate Number 2 CML 24ATEX4334X
ATEX Code of Protection ^ I M2 Ex db I Mb, Ex eb I Mb; ^ II 2G 3G 1D Ex db IIC Gb, Ex eb IIC Gb, Ex nR IIC Gc, Ex ta IIIC Da
ATEX Compliance Standards EN 60079-0, -1, -7, -15, -31
ATEX Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/06617028/64e74f6ad564070019d58c53/atexlogo.jpg
IECEx Certificate Number IECEx CML 24.0137X
IECEx Code of Protection Ex db I Mb, Ex eb I Mb, Ex db IIC Gb, Ex eb IIC Gb, Ex nR IIC Gc, Ex ta IIIC Da
IECEx Compliance Standards IEC 60079-0, -1, -7, -15, -31
IECEx Logo Filename iecexlogo.jpg
IECEx Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/1a644042/685afb8a626fb1a5637e189b/iecexlogo.jpg
Industrial Certificate Number CML 24CA17921
CE Logo Filename CE.jpg
CE Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/e6cd9bc2/64e74da5f9e88500180b83ee/CE.jpg
UKEX Certificate Number CML 24UKEX1335X, CML 24UKEX4336X
UKCA Logo Filename ukcalogo.jpg
UKCA Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/04240f8d/644a532df631055fb7000002/ukcalogo.jpg
EAC Certificate Number EAЭC KZ 7100841.01.01.07859
EAC Code of Protection { 1Ex db IIC Gb X, { 1Ex e IIC Gb X, { 2Ex nR IIC Gc X, { Ex ta IIIC Da X
EAC Logo Filename eaclogo.jpg
EAC Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/0802384c/64425917f6310520f0000001/eaclogo.jpg
UkrSepro Certificate Number CЦ 25.1094X
UkrSepro Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/0802384c/64425917f6310520f000000b/ukrseprologo.jpg
LR Certificate Number LR22320739TA
LR Logo Filename lrlogo.jpg
LR Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/0802384c/64425917f6310520f0000008/lrlogo.jpg
ABS Certificate Number 25-0285992-PDA
ABS Logo Filename abstypelogo.jpg
ABS Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/0802384c/64425917f6310520f000000d/abstypelogo.jpg
INMETRO Certificate Number TÜV 25.0801X
INMETRO Logo Filename inmetrologo.jpg
INMETRO Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/0802384c/64425917f6310520f0000006/inmetrologo.jpg
Taiwan Certificate Number ML141200751312
Taiwan Logo Filename taiwanlogo.jpg
Taiwan Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/1d316014/69302466157771e7acc227bf/taiwanlogo.jpg
Technical Specification
Application EXAT
Armour Clamping Captive ‘Adaptive’ Armour Cone and Captive ‘AnyWay’ Clamping Ring
Seal Material LSF Halogen Free Silicone
Seal Technique CMP Inner Diaphragm Seal and Outer Load Retention Seal
Seal Area(s) Cable Inner Bedding and Cable Outer Sheath
Type Material Options Brass, Nickel Plated Brass, Aluminium, Stainless Steel

* Mechanical classifications applied as per IEC/EN 62444
** When CMP installation accessories are used. Refer to www.cmp-products.com for further information
*** IP68 tested to 300 kPa for 168 hours (equivalent to 30 metres water depth)

Downloads

Certificates

Product Selector

1
Part Number Size Material Entry Thread Entry Thread Size TS Entry Thread Pitch TP Min Overall Cable Ø OS (mm) Max Overall Cable Ø OS (mm) Min Overall Cable Ø OS (Imp) Max Overall Cable Ø OS (Imp) Min Thread Length TL (mm) Min Thread Length TL (Imp) Max Across Flats AF (mm) Max Across Corners AC (mm) Max Across Flats AF (Imp) Max Across Corners AC (Imp) Max Protrusion Length PL (mm) Min Cable Bedding Ø IB (mm) Max Cable Bedding Ø IB (mm) Max Cable Bedding Ø IB (Imp) Min Cable Bedding Ø IB (Imp) Min Armour Thickness X Cone X1 (mm) Max Armour Thickness X Cone X1 (mm) Min Armour Thickness X Cone X1 (Imp) Min Armour Thickness W Cone W1 (mm) Max Armour Thickness W Cone W1 (mm) Min Armour Thickness W Cone W1 (Imp) Max Armour Thickness W Cone W1 (Imp) Shroud Size Ass'y Weight
20S16TFU002 20S16 Brass Metric M20 1.5 6.1 13.2 0.24 0.52 15 0.59 24 26.4 0.94 1.04 71.5 3.1 7 0.12 0.28 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC04 0.14
20TFU002 20 Brass Metric M20 1.5 12.5 20.9 0.49 0.82 15 0.59 30.5 33.6 1.2 1.32 69.8 8 14 0.31 0.55 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC06 0.22
20STFU002 20S Brass Metric M20 1.5 9.5 15.9 0.37 0.63 15 0.59 24 26.4 0.94 1.04 71.5 6 11.6 0.24 0.46 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC04 0.14
20STFU031 20S Brass NPT 1/2" 9.5 15.9 0.37 0.63 19.9 0.78 24 26.4 0.94 1.04 71.5 6 11.6 0.24 0.46 0.2 0.02 0.01 0.8 1.25 0.03 0.05 0.15
20S16TFU031 20S16 Brass NPT 1/2" 6.1 13.2 0.24 0.52 19.9 0.78 24 26.4 0.94 1.04 71.5 3.1 7 0.12 0.28 0.2 0.02 0.01 0.8 1.25 0.03 0.05 0.15
20TFU031 20 Brass NPT 1/2" 12.5 20.9 0.49 0.82 19.9 0.78 30.5 33.6 1.2 1.32 69.8 8 14 0.31 0.55 0.2 0.02 0.01 0.8 1.25 0.03 0.05 0.23
20S16TFU032 20S16 Brass NPT 3/4" 6.1 13.2 0.24 0.52 20.2 0.8 71.5 3.1 7 0.12 0.28 0.2 0.02 0.01 0.8 1.25 0.03 0.05
20TFU032 20 Brass NPT 3/4" 12.5 20.9 0.49 0.82 20.2 0.8 69.8 8 14 0.31 0.55 0.2 0.02 0.01 0.8 1.25 0.03 0.05
20STFU032 20S Brass NPT 3/4" 9.5 15.9 0.37 0.63 20.2 0.8 71.5 6 11.6 0.24 0.46 0.2 0.02 0.01 0.8 1.25 0.03 0.05
20STFU402 20S Stainless Steel Metric M20 1.5 9.5 15.9 0.37 0.63 15 0.59 24 26.4 0.94 1.04 71.5 6 11.6 0.24 0.46 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC04 0.12
20S16TFU402 20S16 Stainless Steel Metric M20 1.5 6.1 13.2 0.24 0.52 15 0.59 24 26.4 0.94 1.04 71.5 3.1 7 0.12 0.28 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC04 0.13
20TFU402 20 Stainless Steel Metric M20 1.5 12.5 20.9 0.49 0.82 15 0.59 30.5 33.6 1.2 1.32 69.8 8 14 0.31 0.55 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC06 0.2
20STFU431 20S Stainless Steel NPT 1/2" 9.5 15.9 0.37 0.63 19.9 0.78 24 26.4 0.94 1.04 71.5 6 11.6 0.24 0.46 0.2 0.02 0.01 0.8 1.25 0.03 0.05 0.14
20S16TFU431 20S16 Stainless Steel NPT 1/2" 6.1 13.2 0.24 0.52 19.9 0.78 24 26.4 0.94 1.04 71.5 3.1 7 0.12 0.28 0.2 0.02 0.01 0.8 1.25 0.03 0.05 0.14
20TFU431 20 Stainless Steel NPT 1/2" 12.5 20.9 0.49 0.82 19.9 0.78 30.5 33.6 1.2 1.32 69.8 8 14 0.31 0.55 0.2 0.02 0.01 0.8 1.25 0.03 0.05 0.21
20TFU432 20 Stainless Steel NPT 3/4" 12.5 20.9 0.49 0.82 20.2 0.8 69.8 8 14 0.31 0.55 0.2 0.02 0.01 0.8 1.25 0.03 0.05
20STFU432 20S Stainless Steel NPT 3/4" 9.5 15.9 0.37 0.63 20.2 0.8 71.5 6 11.6 0.24 0.46 0.2 0.02 0.01 0.8 1.25 0.03 0.05
20S16TFU432 20S16 Stainless Steel NPT 3/4" 6.1 13.2 0.24 0.52 20.2 0.8 71.5 3.1 7 0.12 0.28 0.2 0.02 0.01 0.8 1.25 0.03 0.05
20TFU502 20 Nickel Plated Brass Metric M20 1.5 12.5 20.9 0.49 0.82 15 0.59 30.5 33.6 1.2 1.32 69.8 8 14 0.31 0.55 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC06 0.22
20STFU502 20S Nickel Plated Brass Metric M20 1.5 9.5 15.9 0.37 0.63 15 0.59 24 26.4 0.94 1.04 71.5 6 11.6 0.24 0.46 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC04 0.14
20S16TFU502 20S16 Nickel Plated Brass Metric M20 1.5 6.1 13.2 0.24 0.52 15 0.59 24 26.4 0.94 1.04 71.5 3.1 7 0.12 0.28 0.2 0.02 0.01 0.8 1.25 0.03 0.05 PVC04 0.14
20STFU531 20S Nickel Plated Brass NPT 1/2" 9.5 15.9 0.37 0.63 19.9 0.78 24 26.4 0.94 1.04 71.5 6 11.6 0.24 0.46 0.2 0.02 0.01 0.8 1.25 0.03 0.05 0.15
20S16TFU531 20S16 Nickel Plated Brass NPT 1/2" 6.1 13.2 0.24 0.52 19.9 0.78 24 26.4 0.94 1.04 71.5 3.1 7 0.12 0.28 0.2 0.02 0.01 0.8 1.25 0.03 0.05 0.15
20TFU531 20 Nickel Plated Brass NPT 1/2" 12.5 20.9 0.49 0.82 19.9 0.78 30.5 33.6 1.2 1.32 69.8 8 14 0.31 0.55 0.2 0.02 0.01 0.8 1.25 0.03 0.05 0.23
20STFU532 20S Nickel Plated Brass NPT 3/4" 9.5 15.9 0.37 0.63 20.2 0.8 71.5 6 11.6 0.24 0.46 0.2 0.02 0.01 0.8 1.25 0.03 0.05
20S16TFU532 20S16 Nickel Plated Brass NPT 3/4" 6.1 13.2 0.24 0.52 20.2 0.8 71.5 3.1 7 0.12 0.28 0.2 0.02 0.01 0.8 1.25 0.03 0.05
20TFU532 20 Nickel Plated Brass NPT 3/4" 12.5 20.9 0.49 0.82 20.2 0.8 69.8 8 14 0.31 0.55 0.2 0.02 0.01 0.8 1.25 0.03 0.05
25TFU003 25 Brass Metric M25 1.5 16 26.2 0.63 1.03 15 0.59 37.5 41.3 1.48 1.63 81.1 11 19.5 0.43 0.77 0.2 0.02 0.01 1.3 1.6 0.05 0.06 PVC09 0.35
25TFU032 25 Brass NPT 3/4" 16 26.2 0.63 1.03 20.2 0.8 37.5 41.3 1.48 1.63 81.1 11 19.5 0.43 0.77 0.2 0.02 0.01 1.3 1.6 0.05 0.06 0.36
25TFU033 25 Brass NPT 1" 16 26.2 0.63 1.03 25 0.98 81.1 11 19.5 0.43 0.77 0.2 0.02 0.01 1.3 1.6 0.05 0.06
25TFU403 25 Stainless Steel Metric M25 1.5 16 26.2 0.63 1.03 15 0.59 37.5 41.3 1.48 1.63 81.1 11 19.5 0.43 0.77 0.2 0.02 0.01 1.3 1.6 0.05 0.06 PVC09 0.32
25TFU432 25 Stainless Steel NPT 3/4" 16 26.2 0.63 1.03 20.2 0.8 37.5 41.3 1.48 1.63 81.1 11 19.5 0.43 0.77 0.2 0.02 0.01 1.3 1.6 0.05 0.06 0.33
25TFU433 25 Stainless Steel NPT 1" 16 26.2 0.63 1.03 25 0.98 81.1 11 19.5 0.43 0.77 0.2 0.02 0.01 1.3 1.6 0.05 0.06
25TFU503 25 Nickel Plated Brass Metric M25 1.5 16 26.2 0.63 1.03 15 0.59 37.5 41.3 1.48 1.63 81.1 11 19.5 0.43 0.77 0.2 0.02 0.01 1.3 1.6 0.05 0.06 PVC09 0.35
25TFU532 25 Nickel Plated Brass NPT 3/4" 16 26.2 0.63 1.03 20.2 0.8 37.5 41.3 1.48 1.63 81.1 11 19.5 0.43 0.77 0.2 0.02 0.01 1.3 1.6 0.05 0.06 0.36
25TFU533 25 Nickel Plated Brass NPT 1" 16 26.2 0.63 1.03 25 0.98 81.1 11 19.5 0.43 0.77 0.2 0.02 0.01 1.3 1.6 0.05 0.06
32TFU004 32 Brass Metric M32 1.5 21.5 33.9 0.85 1.33 15 0.59 46 50.6 1.81 1.99 89.8 17 26.5 0.67 1.04 0.2 0.02 0.01 1.6 2 0.06 0.08 PVC11 0.54
32TFU033 32 Brass NPT 1" 21.5 33.9 0.85 1.33 25 0.98 46 50.6 1.81 1.99 89.8 17 26.5 0.67 1.04 0.2 0.02 0.01 1.6 2 0.06 0.08 0.55
32TFU034 32 Brass NPT 1-1/4" 21.5 33.9 0.85 1.33 25.6 1.01 89.8 17 26.5 0.67 1.04 0.2 0.02 0.01 1.6 2 0.06 0.08
32TFU404 32 Stainless Steel Metric M32 1.5 21.5 33.9 0.85 1.33 15 0.59 46 50.6 1.81 1.99 89.8 17 26.5 0.67 1.04 0.2 0.02 0.01 1.6 2 0.06 0.08 PVC11 0.49
32TFU433 32 Stainless Steel NPT 1" 21.5 33.9 0.85 1.33 25 0.98 46 50.6 1.81 1.99 89.8 17 26.5 0.67 1.04 0.2 0.02 0.01 1.6 2 0.06 0.08 0.5
32TFU434 32 Stainless Steel NPT 1-1/4" 21.5 33.9 0.85 1.33 25.6 1.01 89.8 17 26.5 0.67 1.04 0.2 0.02 0.01 1.6 2 0.06 0.08
32TFU504 32 Nickel Plated Brass Metric M32 1.5 21.5 33.9 0.85 1.33 15 0.59 46 50.6 1.81 1.99 89.8 17 26.5 0.67 1.04 0.2 0.02 0.01 1.6 2 0.06 0.08 PVC11 0.54
32TFU533 32 Nickel Plated Brass NPT 1" 21.5 33.9 0.85 1.33 25 0.98 46 50.6 1.81 1.99 89.8 17 26.5 0.67 1.04 0.2 0.02 0.01 1.6 2 0.06 0.08 0.55
32TFU534 32 Nickel Plated Brass NPT 1-1/4" 21.5 33.9 0.85 1.33 25.6 1.01 89.8 17 26.5 0.67 1.04 0.2 0.02 0.01 1.6 2 0.06 0.08
40TFU005 40 Brass Metric M40 1.5 28 40.4 1.1 1.59 15 0.59 55 60.5 2.17 2.38 92.8 22 32 0.87 1.26 0.2 0.03 0.01 1.6 2 0.06 0.08 PVC15 0.76
40TFU034 40 Brass NPT 1-1/4" 28 40.4 1.1 1.59 25.6 1.01 55 60.5 2.17 2.38 92.8 22 32 0.87 1.26 0.2 0.03 0.01 1.6 2 0.06 0.08 0.81
40TFU035 40 Brass NPT 1-1/2" 28 40.4 1.1 1.59 26.1 1.03 92.8 22 32 0.87 1.26 0.2 0.03 0.01 1.6 2 0.06 0.08
40TFU405 40 Stainless Steel Metric M40 1.5 28 40.4 1.1 1.59 15 0.59 55 60.5 2.17 2.38 92.8 22 32 0.87 1.26 0.2 0.03 0.01 1.6 2 0.06 0.08 PVC15 0.71
40TFU434 40 Stainless Steel NPT 1-1/4" 28 40.4 1.1 1.59 25.6 1.01 55 60.5 2.17 2.38 92.8 22 32 0.87 1.26 0.2 0.03 0.01 1.6 2 0.06 0.08 0.75
40TFU435 40 Stainless Steel NPT 1-1/2" 28 40.4 1.1 1.59 26.1 1.03 92.8 22 32 0.87 1.26 0.2 0.03 0.01 1.6 2 0.06 0.08
40TFU505 40 Nickel Plated Brass Metric M40 1.5 28 40.4 1.1 1.59 15 0.59 55 60.5 2.17 2.38 92.8 22 32 0.87 1.26 0.2 0.03 0.01 1.6 2 0.06 0.08 PVC15 0.76
40TFU534 40 Nickel Plated Brass NPT 1-1/4" 28 40.4 1.1 1.59 25.6 1.01 55 60.5 2.17 2.38 92.8 22 32 0.87 1.26 0.2 0.03 0.01 1.6 2 0.06 0.08 0.81
40TFU535 40 Nickel Plated Brass NPT 1-1/2" 28 40.4 1.1 1.59 26.1 1.03 92.8 22 32 0.87 1.26 0.2 0.03 0.01 1.6 2 0.06 0.08
50TFU006 50 Brass Metric M50 1.5 38 53.2 1.5 2.09 15 0.59 70 77 2.76 3.03 101.3 29.5 44 1.16 1.73 0.3 0.03 0.01 2 2.5 0.08 0.1 PVC21 1.2
50TFU035 50 Brass NPT 1-1/2" 38 53.2 1.5 2.09 26.1 1.03 70 77 2.76 3.03 101.3 29.5 44 1.16 1.73 0.3 0.03 0.01 2 2.5 0.08 0.1
50TFU036 50 Brass NPT 2" 38 53.2 1.5 2.09 26.9 1.06 70 77 2.76 3.03 101.3 29.5 44 1.16 1.73 0.3 0.03 0.01 2 2.5 0.08 0.1 1.38
50TFU037 50 Brass NPT 2-1/2" 38 53.2 1.5 2.09 39.9 1.57 101.3 29.5 44 1.16 1.73 0.3 0.03 0.01 2 2.5 0.08 0.1
50TFU406 50 Stainless Steel Metric M50 1.5 38 53.2 1.5 2.09 15 0.59 70 77 2.76 3.03 101.3 29.5 44 1.16 1.73 0.3 0.03 0.01 2 2.5 0.08 0.1 PVC21 1.11
50TFU435 50 Stainless Steel NPT 1-1/2" 38 53.2 1.5 2.09 26.1 1.03 70 77 2.76 3.03 101.3 29.5 44 1.16 1.73 0.3 0.03 0.01 2 2.5 0.08 0.1
50TFU436 50 Stainless Steel NPT 2" 38 53.2 1.5 2.09 26.9 1.06 70 77 2.76 3.03 101.3 29.5 44 1.16 1.73 0.3 0.03 0.01 2 2.5 0.08 0.1 1.27
50TFU437 50 Stainless Steel NPT 2-1/2" 38 53.2 1.5 2.09 39.9 1.57 101.3 29.5 44 1.16 1.73 0.3 0.03 0.01 2 2.5 0.08 0.1
50TFU506 50 Nickel Plated Brass Metric M50 1.5 38 53.2 1.5 2.09 15 0.59 70 77 2.76 3.03 101.3 29.5 44 1.16 1.73 0.3 0.03 0.01 2 2.5 0.08 0.1 PVC21 1.2
50TFU535 50 Nickel Plated Brass NPT 1-1/2" 38 53.2 1.5 2.09 26.1 1.03 70 77 2.76 3.03 101.3 29.5 44 1.16 1.73 0.3 0.03 0.01 2 2.5 0.08 0.1
50TFU536 50 Nickel Plated Brass NPT 2" 38 53.2 1.5 2.09 26.9 1.06 70 77 2.76 3.03 101.3 29.5 44 1.16 1.73 0.3 0.03 0.01 2 2.5 0.08 0.1 1.38
50TFU537 50 Nickel Plated Brass NPT 2-1/2" 38 53.2 1.5 2.09 39.9 1.57 101.3 29.5 44 1.16 1.73 0.3 0.03 0.01 2 2.5 0.08 0.1
63TFU007 63 Brass Metric M63 1.5 52 66 2.05 2.6 15 0.59 80 88 3.15 3.46 112.9 41.5 55 1.63 2.17 0.3 0.03 0.01 2 2.5 0.08 0.1 PVC25 1.49
63TFU036 63 Brass NPT 2" 52 66 2.05 2.6 26.9 1.06 80 88 3.15 3.46 112.9 41.5 55 1.63 2.17 0.3 0.03 0.01 2 2.5 0.08 0.1
63TFU037 63 Brass NPT 2-1/2" 52 66 2.05 2.6 39.9 1.57 80 88 3.15 3.46 112.9 41.5 55 1.63 2.17 0.3 0.03 0.01 2 2.5 0.08 0.1 2.01
63TFU038 63 Brass NPT 3" 52 66 2.05 2.6 41.5 1.63 112.9 41.5 55 1.63 2.17 0.3 0.03 0.01 2 2.5 0.08 0.1
63TFU407 63 Stainless Steel Metric M63 1.5 52 66 2.05 2.6 15 0.59 80 88 3.15 3.46 112.9 41.5 55 1.63 2.17 0.3 0.03 0.01 2 2.5 0.08 0.1 PVC25 1.38
63TFU436 63 Stainless Steel NPT 2" 52 66 2.05 2.6 26.9 1.06 80 88 3.15 3.46 112.9 41.5 55 1.63 2.17 0.3 0.03 0.01 2 2.5 0.08 0.1
63TFU437 63 Stainless Steel NPT 2-1/2" 52 66 2.05 2.6 39.9 1.57 80 88 3.15 3.46 112.9 41.5 55 1.63 2.17 0.3 0.03 0.01 2 2.5 0.08 0.1 1.85
63TFU438 63 Stainless Steel NPT 3" 52 66 2.05 2.6 41.5 1.63 112.9 41.5 55 1.63 2.17 0.3 0.03 0.01 2 2.5 0.08 0.1
63TFU507 63 Nickel Plated Brass Metric M63 1.5 52 66 2.05 2.6 15 0.59 80 88 3.15 3.46 112.9 41.5 55 1.63 2.17 0.3 0.03 0.01 2 2.5 0.08 0.1 PVC25 1.49
63TFU536 63 Nickel Plated Brass NPT 2" 52 66 2.05 2.6 26.9 1.06 80 88 3.15 3.46 112.9 41.5 55 1.63 2.17 0.3 0.03 0.01 2 2.5 0.08 0.1
63TFU537 63 Nickel Plated Brass NPT 2-1/2" 52 66 2.05 2.6 39.9 1.57 80 88 3.15 3.46 112.9 41.5 55 1.63 2.17 0.3 0.03 0.01 2 2.5 0.08 0.1 2.01
63TFU538 63 Nickel Plated Brass NPT 3" 52 66 2.05 2.6 41.5 1.63 112.9 41.5 55 1.63 2.17 0.3 0.03 0.01 2 2.5 0.08 0.1
75TFU008 75 Brass Metric M75 1.5 64.5 78.5 2.54 3.09 15 0.59 100 110 3.94 4.33 112.4 53.5 68 2.11 2.68 0.3 0.03 0.01 2.5 3.15 0.1 0.12 PVC30 2.61
75TFU037 75 Brass NPT 2-1/2" 64.5 78.5 2.54 3.09 39.9 1.57 100 110 3.94 4.33 112.4 53.5 68 2.11 2.68 0.3 0.03 0.01 2.5 3.15 0.1 0.12
75TFU038 75 Brass NPT 3" 64.5 78.5 2.54 3.09 41.5 1.63 100 110 3.94 4.33 112.4 53.5 68 2.11 2.68 0.3 0.03 0.01 2.5 3.15 0.1 0.12 3.5
75TFU039 75 Brass NPT 3-1/2" 64.5 78.5 2.54 3.09 42.8 1.69 112.4 53.5 68 2.11 2.68 0.3 0.03 0.01 2.5 3.15 0.1 0.12
75TFU408 75 Stainless Steel Metric M75 1.5 64.5 78.5 2.54 3.09 15 0.59 100 110 3.94 4.33 112.4 53.5 68 2.11 2.68 0.3 0.03 0.01 2.5 3.15 0.1 0.12 PVC30 2.41
75TFU437 75 Stainless Steel NPT 2-1/2" 64.5 78.5 2.54 3.09 39.9 1.57 100 110 3.94 4.33 112.4 53.5 68 2.11 2.68 0.3 0.03 0.01 2.5 3.15 0.1 0.12
75TFU438 75 Stainless Steel NPT 3" 64.5 78.5 2.54 3.09 41.5 1.63 100 110 3.94 4.33 112.4 53.5 68 2.11 2.68 0.3 0.03 0.01 2.5 3.15 0.1 0.12 3.21
75TFU439 75 Stainless Steel NPT 3-1/2" 64.5 78.5 2.54 3.09 42.8 1.69 112.4 53.5 68 2.11 2.68 0.3 0.03 0.01 2.5 3.15 0.1 0.12
75TFU508 75 Nickel Plated Brass Metric M75 1.5 64.5 78.5 2.54 3.09 15 0.59 100 110 3.94 4.33 112.4 53.5 68 2.11 2.68 0.3 0.03 0.01 2.5 3.15 0.1 0.12 PVC30 2.61
75TFU537 75 Nickel Plated Brass NPT 2-1/2" 64.5 78.5 2.54 3.09 39.9 1.57 100 110 3.94 4.33 112.4 53.5 68 2.11 2.68 0.3 0.03 0.01 2.5 3.15 0.1 0.12
75TFU538 75 Nickel Plated Brass NPT 3" 64.5 78.5 2.54 3.09 41.5 1.63 100 110 3.94 4.33 112.4 53.5 68 2.11 2.68 0.3 0.03 0.01 2.5 3.15 0.1 0.12 3.5
75TFU539 75 Nickel Plated Brass NPT 3-1/2" 64.5 78.5 2.54 3.09 42.8 1.69 112.4 53.5 68 2.11 2.68 0.3 0.03 0.01 2.5 3.15 0.1 0.12
90TFU009 90 Brass Metric M90 2 75 90.5 2.95 3.56 24 0.94 114 125.4 4.49 4.94 150.3 66 78.5 2.6 3.09 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC32 4.91
90TFU039 90 Brass NPT 3-1/2" 75 90.5 2.95 3.56 42.8 1.69 114 125.4 4.49 4.94 150.3 66 78.5 2.6 3.09 0.4 0.03 0.02 3.15 4 0.12 0.16 5.61
90TFU0310 90 Brass NPT 4" 75 90.5 2.95 3.56 44 1.73 150.3 66 78.5 2.6 3.09 0.4 0.03 0.02 3.15 4 0.12 0.16
90TFU409 90 Stainless Steel Metric M90 2 75 90.5 2.95 3.56 24 0.94 114 125.4 4.49 4.94 150.3 66 78.5 2.6 3.09 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC32 4.52
90TFU439 90 Stainless Steel NPT 3-1/2" 75 90.5 2.95 3.56 42.8 1.69 114 125.4 4.49 4.94 150.3 66 78.5 2.6 3.09 0.4 0.03 0.02 3.15 4 0.12 0.16 5.15
90TFU509 90 Nickel Plated Brass Metric M90 2 75 90.5 2.95 3.56 24 0.94 114 125.4 4.49 4.94 150.3 66 78.5 2.6 3.09 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC32 4.91
90TFU539 90 Nickel Plated Brass NPT 3-1/2" 75 90.5 2.95 3.56 42.8 1.69 114 125.4 4.49 4.94 150.3 66 78.5 2.6 3.09 0.4 0.03 0.02 3.15 4 0.12 0.16 5.61
90TFU4310 90 Stainless Steel NPT 4" 75 90.5 2.95 3.56 44 1.73 150.3 66 78.5 2.6 3.09 0.4 0.03 0.02 3.15 4 0.12 0.16
90TFU5310 90 Nickel Plated Brass NPT 4" 75 90.5 2.95 3.56 44 1.73 150.3 66 78.5 2.6 3.09 0.4 0.03 0.02 3.15 4 0.12 0.16
100TFU0010 100 Brass Metric M100 2 86 101.5 3.39 4 24 0.94 123 135.3 4.84 5.33 160.2 76 90.5 2.99 3.56 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC33 5.22
100TFU039 100 Brass NPT 3-1/2" 86 101.5 3.39 4 42.8 1.69 123 135.3 4.84 5.33 160.2 76 90.5 2.99 3.56 0.4 0.03 0.02 3.15 4 0.12 0.16 5.24
100TFU0310 100 Brass NPT 4" 86 101.5 3.39 4 44 1.73 160.2 76 90.5 2.99 3.56 0.4 0.03 0.02 3.15 4 0.12 0.16
100TFU439 100 Stainless Steel NPT 3-1/2" 86 101.5 3.39 4 42.8 1.69 123 135.3 4.84 5.33 160.2 76 90.5 2.99 3.56 0.4 0.03 0.02 3.15 4 0.12 0.16 5
100TFU539 100 Nickel Plated Brass NPT 3-1/2" 86 101.5 3.39 4 42.8 1.69 123 135.3 4.84 5.33 160.2 76 90.5 2.99 3.56 0.4 0.03 0.02 3.15 4 0.12 0.16 5.24
100TFU4010 100 Stainless Steel Metric M100 2 86 101.5 3.39 4 24 0.94 123 135.3 4.84 5.33 160.2 76 90.5 2.99 3.56 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC33 4.82
100TFU4310 100 Stainless Steel NPT 4" 86 101.5 3.39 4 44 1.73 160.2 76 90.5 2.99 3.56 0.4 0.03 0.02 3.15 4 0.12 0.16
100TFU5010 100 Nickel Plated Brass Metric M100 2 86 101.5 3.39 4 24 0.94 123 135.3 4.84 5.33 160.2 76 90.5 2.99 3.56 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC33 5.22
100TFU5310 100 Nickel Plated Brass NPT 4" 86 101.5 3.39 4 44 1.73 160.2 76 90.5 2.99 3.56 0.4 0.03 0.02 3.15 4 0.12 0.16
115TFU0011 115 Brass Metric M115 2 101 110.5 3.98 4.35 24 0.94 133 146.3 5.24 5.76 180.7 86 98 3.39 3.86 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC34 7.25
115TFU0310 115 Brass NPT 4" 101 110.5 3.98 4.35 44 1.73 133 146.3 5.24 5.76 180.7 86 98 3.39 3.86 0.4 0.03 0.02 3.15 4 0.12 0.16 7.51
115TFU0312 115 Brass NPT 5" 101 110.5 3.98 4.35 46.8 1.84 180.7 86 98 3.39 3.86 0.4 0.03 0.02 3.15 4 0.12 0.16
115TFU4011 115 Stainless Steel Metric M115 2 101 110.5 3.98 4.35 24 0.94 133 146.3 5.24 5.76 180.7 86 98 3.39 3.86 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC34 6.7
115TFU4310 115 Stainless Steel NPT 4" 101 110.5 3.98 4.35 44 1.73 133 146.3 5.24 5.76 180.7 86 98 3.39 3.86 0.4 0.03 0.02 3.15 4 0.12 0.16 6.94
115TFU4312 115 Stainless Steel NPT 5" 101 110.5 3.98 4.35 46.8 1.84 180.7 86 98 3.39 3.86 0.4 0.03 0.02 3.15 4 0.12 0.16
115TFU5011 115 Nickel Plated Brass Metric M115 2 101 110.5 3.98 4.35 24 0.94 133 146.3 5.24 5.76 180.7 86 98 3.39 3.86 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC34 7.25
115TFU5310 115 Nickel Plated Brass NPT 4" 101 110.5 3.98 4.35 44 1.73 133 146.3 5.24 5.76 180.7 86 98 3.39 3.86 0.4 0.03 0.02 3.15 4 0.12 0.16 7.51
115TFU5312 115 Nickel Plated Brass NPT 5" 101 110.5 3.98 4.35 46.8 1.84 180.7 86 98 3.39 3.86 0.4 0.03 0.02 3.15 4 0.12 0.16
130TFU0012 130 Brass Metric M130 2 110 123.5 4.33 4.8 24 0.94 153 168.3 6.02 6.6 191.5 97 115 3.82 4.53 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC35 9.47
130TFU0312 130 Brass NPT 5" 110 123.5 4.33 4.8 46.8 1.84 153 168.3 6.02 6.6 191.5 97 115 3.82 4.53 0.4 0.03 0.02 3.15 4 0.12 0.16 9.72
130TFU4012 130 Stainless Steel Metric M130 2 110 123.5 4.33 4.8 24 0.94 153 168.3 6.02 6.6 191.5 97 115 3.82 4.53 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC35 8.75
130TFU4312 130 Stainless Steel NPT 5" 110 123.5 4.33 4.8 46.8 1.84 153 168.3 6.02 6.6 191.5 97 115 3.82 4.53 0.4 0.03 0.02 3.15 4 0.12 0.16 8.88
130TFU5012 130 Nickel Plated Brass Metric M130 2 110 123.5 4.33 4.8 24 0.94 153 168.3 6.02 6.6 191.5 97 115 3.82 4.53 0.4 0.03 0.02 3.15 4 0.12 0.16 PVC35 9.47
130TFU5312 130 Nickel Plated Brass NPT 5" 110 123.5 4.33 4.8 46.8 1.84 153 168.3 6.02 6.6 191.5 97 115 3.82 4.53 0.4 0.03 0.02 3.15 4 0.12 0.16 9.72
1
No results

0 of 123 Selected

Your Shortlist

    Your Selection

      "*" indicates required fields

      We'd like to keep in touch

      We have some exciting things in the pipeline - if you'd like to be the first to know please enter your email address below.

      No thanks, I'd just like to Download the datasheets
