TSPeExi Cable Gland

ETIM Classification

EC000441

For all types of Unarmoured & Braided / Screened Cables

Description

Features

  • Blue nut for intrinsically safe (Ex i) identification
  • Halogen and phosphorus-free
  • Unique strain relief sealing system
  • Approved to the latest editions of IEC/EN 60079
  • Internationally marked IECEx, ATEX and UKEX
  • 3rd party certified to IEC/EN 62444
  • Widest cable range take for any comparable cable gland
  • Low weight with high stiffness and strength
  • Anti-vibration technology prevents seal loosening in operation
  • Transit disc or IP68, IP69 and IP69K rated IP plug options available
  • Approved entry thread sealing washer included
  • For clearance holes the TSPe must be installed using a CMP metallic locknut (available with the cable gland using ordering suffix 2TN)

Additional Information

Certification
ATEX Certificate Number CML 19ATEX3185X
ATEX Certificate Number 2 CML 19ATEX4186X
ATEX Code of Protection ^ II 2G 3G 1D Ex eb IIC Gb, Ex nR IIC Gc, Ex ta IIIC Da
ATEX Compliance Standards EN 60079-0, -7, -15, -31
ATEX Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/0802384c/64425917f6310520f0000002/atexlogo.jpg
IECEx Certificate Number IECEx CML 19.0062X
IECEx Code of Protection Ex eb IIC Gb, Ex nR IIC Gc, Ex ta IIIC Da
IECEx Compliance Standards IEC 60079-0, -7, -15, -31
IECEx Logo Filename iecexlogo.jpg
IECEx Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/990ba9ce/6447a914b902aa64e3000252/iecexlogo.jpg
UKEX Certificate Number CML 21UKEX3264X
UKCA Logo Filename ukcalogo.jpg
UKCA Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/04240f8d/644a532df631055fb7000002/ukcalogo.jpg
EAC Certificate Number EAЭC RU C-GB.AꙢ07.B.02516/20
EAC Code of Protection { 1Ex e IIC Gb X, { 2Ex nR IIC Gc X, { Ex ta IIIC Da X
EAC Logo Filename eaclogo.jpg
EAC Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/0802384c/64425917f6310520f0000001/eaclogo.jpg
CCC Certificate Number 2020322313003450
CCC Logo Filename ccclogo.jpg
CCC Logo https://cdn.pimber.ly/public/asset/raw/62c2cfa03a6b3a001b063277/cf29f9f6/644a38e4f631055a56000001/ccclogo.jpg
SANS Certificate Number S-XPL/21.0014 X
Technical Specification
Application EXAT
Seal Material CMP SOLO LSF Halogen-free Thermoset Elastomer
Seal Technique CMP Unique finger-locking type seal
Seal Area(s) Cable Outer Sheath
Seal Types Array
Accessory Types Array
Colours Array
Thread Types 2 Array

* Mechanical classifications applied as per IEC/EN 62444 ** IP68 tested to 300 kPa for 16 hours (equivalent to 30 metres water depth

Downloads

Certificates

Product Selector

1
Part Number Size Material Entry Thread Entry Thread Size TS Entry Thread Pitch TP Min Overall Cable Ø OS (mm) Max Overall Cable Ø OS (mm) Min Overall Cable Ø OS (Imp) Max Overall Cable Ø OS (Imp) Min Thread Length TL (mm) Min Thread Length TL (Imp) Max Across Flats AF (mm) Max Across Corners AC (mm) Max Across Flats AF (Imp) Max Across Corners AC (Imp) Max Protrusion Length PL (mm)
12TSPE2TPN4T 12 Halogen Free Polyamide NPT 1/4" 3 6.5 0.12 0.26 11 0.43 15 16.4 0.59 0.65 27
12TSPE2TDN4T 12 Halogen Free Polyamide NPT 1/4" 3 6.5 0.12 0.26 11 0.43 15 16.4 0.59 0.65 27
12TSPE2TDN4L 12 Halogen Free Polyamide Metric (Tru) M12 1.5 3 6.5 0.12 0.26 9 0.35 15 16.4 0.59 0.65 27
12TSPE1TD4T 12 Halogen Free Polyamide NPT 1/4" 3 6.5 0.12 0.26 11 0.43 15 16.4 0.59 0.65 27
12TSPE1TD4L 12 Halogen Free Polyamide Metric (Tru) M12 1.5 3 6.5 0.12 0.26 9 0.35 15 16.4 0.59 0.65 27
12TSPE2TDN4 12 Halogen Free Polyamide Metric (Tru) M12 1.5 3 6.5 0.12 0.26 9 0.35 15 16.4 0.59 0.65 27
12TSPE1TD4 12 Halogen Free Polyamide Metric (Tru) M12 1.5 3 6.5 0.12 0.26 9 0.35 15 16.4 0.59 0.65 27
12TSPE2TPN4 12 Halogen Free Polyamide Metric (Tru) M12 1.5 3 6.5 0.12 0.26 9 0.35 15 16.4 0.59 0.65 27
16DTSPE1TD4L 16D Halogen Free Polyamide Metric (Tru) M16 1.5 3 10 0.12 0.39 9 0.35 19 20.9 0.75 0.82 27
16DTSPE1TD4T 16D Halogen Free Polyamide NPT 3/8" 3 10 0.12 0.39 11 0.43 19 20.9 0.75 0.82 27
16TSPE2TDN4L 16 Halogen Free Polyamide Metric (Tru) M16 1.5 6 10 0.24 0.39 9 0.35 19 20.9 0.75 0.82 27
16TSPE2TDN4T 16 Halogen Free Polyamide NPT 3/8" 6 10 0.24 0.39 11 0.43 19 20.9 0.75 0.82 27
16TSPE1TD4T 16 Halogen Free Polyamide NPT 3/8" 6 10 0.24 0.39 11 0.43 19 20.9 0.75 0.82 27
16TSPE1TD4L 16 Halogen Free Polyamide Metric (Tru) M16 1.5 6 10 0.24 0.39 9 0.35 19 20.9 0.75 0.82 27
16FF1TSPE2TDN4T 25 Halogen Free Polyamide NPT 3/8" 7mm x 4mm 8.2mm x 5.0mm 11 0.43 19 20.9 0.75 0.82 27
16MS2TSPE2MSNK4T 16 Halogen Free Polyamide NPT 3/8" 3 x 1mm 3 x 2mm 11 0.43 19 20.9 0.75 0.82 27
16DTSPE2TPN4T 16D Halogen Free Polyamide NPT 3/8" 3 10 0.12 0.39 11 0.43 19 20.9 0.75 0.82 27
16FF2TSPE2TDN4T 25 Halogen Free Polyamide NPT 3/8" 8mm x 4mm 10mm x 6.0mm 11 0.43 19 20.9 0.75 0.82 27
16MS2TSPE2MSNK4L 16 Halogen Free Polyamide Metric (Tru) M16 1.5 3 x 1mm 3 x 2mm 9 0.35 19 20.9 0.75 0.82 27
16FF1TSPE2TDN4L 16 Halogen Free Polyamide Metric (Tru) M16 1.5 7mm x 4mm 8.2mm x 5.0mm 9 0.35 19 20.9 0.75 0.82 27
16FF2TSPE2TDN4L 16 Halogen Free Polyamide Metric (Tru) M16 1.5 8mm x 4mm 10mm x 6.0mm 9 0.35 19 20.9 0.75 0.82 27
16MS1TSPE2MSNK4T 16 Halogen Free Polyamide NPT 3/8" 2 x 3mm 2 x 4mm 11 0.43 19 20.9 0.75 0.82 27
16MS1TSPE2MSNK4L 16 Halogen Free Polyamide Metric (Tru) M16 1.5 2 x 2mm 2 x 4mm 9 0.35 19 20.9 0.75 0.82 27
16TSPE2TPN4T 16 Halogen Free Polyamide NPT 3/8" 6 10 0.24 0.39 11 0.43 19 20.9 0.75 0.82 27
16DTSPE2TDN4L 16D Halogen Free Polyamide Metric (Tru) M16 1.5 3 10 0.12 0.39 9 0.35 19 20.9 0.75 0.82 27
16DTSPE2TDN4T 16D Halogen Free Polyamide NPT 3/8" 3 10 0.12 0.39 11 0.43 19 20.9 0.75 0.82 27
16DTSPE1TD4 16D Halogen Free Polyamide Metric (Tru) M16 1.5 3 10 0.12 0.39 9 0.35 19 20.9 0.75 0.82 27
16TSPE2TDN4 16 Halogen Free Polyamide Metric (Tru) M16 1.5 6 10 0.24 0.39 9 0.35 19 20.9 0.75 0.82 27
16MS1TSPE1TD4 16 Halogen Free Polyamide Metric (Tru) M16 1.5 2 x 3mm 2 x 4mm 9 0.35 19 20.9 0.75 0.82 27
16TSPE1TD4 16 Halogen Free Polyamide Metric (Tru) M16 1.5 6 10 0.24 0.39 9 0.35 19 20.9 0.75 0.82 27
16MS2TSPE1TD4 16 Halogen Free Polyamide Metric (Tru) M16 1.5 3 x 1mm 3 x 2mm 9 0.35 19 20.9 0.75 0.82 27
16MS2TSPE2MSNK4 16 Halogen Free Polyamide Metric (Tru) M16 1.5 2 x 3mm 2 x 4mm 9 0.35 19 20.9 0.75 0.82 27
16TSPE2TPN4 16 Halogen Free Polyamide Metric (Tru) M16 1.5 6 10 0.24 0.39 9 0.35 19 20.9 0.75 0.82 27
16FF1TSPE2TDN4 16 Halogen Free Polyamide Metric (Tru) M16 1.5 7mm x 4mm 8.2mm x 5.0mm 9 0.35 19 20.9 0.75 0.82 27
16FF2TSPE2TDN4 16 Halogen Free Polyamide Metric (Tru) M16 1.5 8mm x 4mm 10mm x 6.0mm 9 0.35 19 20.9 0.75 0.82 27
16MS1TSPE2MSNK4 16 Halogen Free Polyamide Metric (Tru) M16 1.5 2 x 3mm 2 x 4mm 9 0.35 19 20.9 0.75 0.82 27
16DTSPE2TPN4 16D Halogen Free Polyamide Metric (Tru) M16 1.5 3 10 0.12 0.39 9 0.35 19 20.9 0.75 0.82 27
16DTSPE2TDN4 16D Halogen Free Polyamide Metric (Tru) M16 1.5 3 10 0.12 0.39 9 0.35 19 20.9 0.75 0.82 27
20DTSPE1TD4L 20D Halogen Free Polyamide Metric (Tru) M20 1.5 5 14 0.2 0.55 10 0.39 24 26.2 0.95 1.03 30.5
20DTSPE1TD4T 20D Halogen Free Polyamide NPT 1/2" 5 14 0.2 0.55 14 0.55 24 26.2 0.95 1.03 30.5
20FF3TSPE2TDN4T 25 Halogen Free Polyamide NPT 1/2" 10mm x 4mm 11.9mm x 6.25mm 14 0.55 24 26.2 0.95 1.03 30.5
20TSPE1TD4T 20 Halogen Free Polyamide NPT 1/2" 9 14 0.35 0.55 14 0.55 24 26.2 0.95 1.03 30.5
20TSPE2TDN4L 20 Halogen Free Polyamide Metric (Tru) M20 1.5 9 14 0.35 0.55 10 0.39 24 26.2 0.95 1.03 30.5
20FF3TSPE2TDN4L 20 Halogen Free Polyamide Metric (Tru) M20 1.5 10mm x 4mm 11.9mm x 6.25mm 10 0.39 24 26.2 0.95 1.03 30.5
20MS3TSPE2MSNK4T 20 Halogen Free Polyamide NPT 1/2" 4 x 3mm 4 x 4mm 14 0.55 24 26.2 0.95 1.03 30.5
20TSPE1TD4L 20 Halogen Free Polyamide Metric (Tru) M20 1.5 9 14 0.35 0.55 10 0.39 24 26.2 0.95 1.03 30.5
20FF1TSPE2TDN4T 25 Halogen Free Polyamide NPT 1/2" 7mm x 4mm 8.2mm x 5.0mm 14 0.55 24 26.2 0.95 1.03 30.5
20DTSPE2TPN4T 20D Halogen Free Polyamide NPT 1/2" 5 14 0.2 0.55 14 0.55 24 26.2 0.95 1.03 30.5
20FF2TSPE2TDN4T 25 Halogen Free Polyamide NPT 1/2" 8mm x 4mm 10.3mm x 6.0mm 14 0.55 24 26.2 0.95 1.03 30.5
20FF1TSPE2TDN4L 20 Halogen Free Polyamide Metric (Tru) M20 1.5 7mm x 4mm 8.2mm x 5.0mm 10 0.39 24 26.2 0.95 1.03 30.5
20MS2TSPE2MSNK4T 20 Halogen Free Polyamide NPT 1/2" 3 x 3mm 3 x 4mm 14 0.55 24 26.2 0.95 1.03 30.5
20MS2TSPE2MSNK4L 20 Halogen Free Polyamide Metric (Tru) M20 1.5 3 x 3mm 3 x 4mm 10 0.39 24 26.2 0.95 1.03 30.5
20MS3TSPE2MSNK4L 20 Halogen Free Polyamide Metric (Tru) M20 1.5 4 x 3mm 4 x 4mm 10 0.39 24 26.2 0.95 1.03 30.5
20FF2TSPE2TDN4L 20 Halogen Free Polyamide Metric (Tru) M20 1.5 8mm x 4mm 10.3mm x 6.0mm 10 0.39 24 26.2 0.95 1.03 30.5
20MS1TSPE2MSNK4T 20 Halogen Free Polyamide NPT 1/2" 2 x 3mm 2 x 5mm 14 0.55 24 26.2 0.95 1.03 30.5
20FF4TSPE2TDN4T 25 Halogen Free Polyamide NPT 1/2" 11mm x 4mm 13.5mm x 7.0mm 14 0.55 24 26.2 0.95 1.03 30.5
20MS1TSPE2MSNK4L 20 Halogen Free Polyamide Metric (Tru) M20 1.5 2 x 3mm 2 x 5mm 10 0.39 24 26.2 0.95 1.03 30.5
20FF4TSPE2TDN4L 20 Halogen Free Polyamide Metric (Tru) M20 1.5 11mm x 4mm 13.5mm x 7.0mm 10 0.39 24 26.2 0.95 1.03 30.5
20TSPE2TPN4T 20 Halogen Free Polyamide NPT 1/2" 9 14 0.35 0.55 14 0.55 24 26.2 0.95 1.03 30.5
20DTSPE2TDN4T 20D Halogen Free Polyamide NPT 1/2" 5 14 0.2 0.55 14 0.55 24 26.2 0.95 1.03 30.5
20DTSPE2TDN4L 20D Halogen Free Polyamide Metric (Tru) M20 1.5 5 14 0.2 0.55 10 0.39 24 26.2 0.95 1.03 30.5
20TSPE2TDN4T 20 Halogen Free Polyamide NPT 1/2" 9 14 0.35 0.55 14 0.55 24 26.2 0.95 1.03 30.5
20FF3TSPE2TDN4 20 Halogen Free Polyamide Metric (Tru) M20 1.5 10mm x 4mm 11.9mm x 6.25mm 10 0.39 24 26.2 0.95 1.03 30.5
20MS1TSPE1TD4 20 Halogen Free Polyamide Metric (Tru) M20 1.5 2 x 3mm 2 x 5mm 10 0.39 24 26.2 0.95 1.03 30.5
20MS3TSPE2MSNK4 20 Halogen Free Polyamide Metric (Tru) M20 1.5 4 x 3mm 4 x 4mm 10 0.39 24 26.2 0.95 1.03 30.5
20MS2TSPE1TD4 20 Halogen Free Polyamide Metric (Tru) M20 1.5 3 x 3mm 3 x 4mm 10 0.39 24 26.2 0.95 1.03 30.5
20TSPE2TPN4 20 Halogen Free Polyamide Metric (Tru) M20 1.5 9 14 0.35 0.55 10 0.39 24 26.2 0.95 1.03 30.5
20FF1TSPE2TDN4 20 Halogen Free Polyamide Metric (Tru) M20 1.5 7mm x 4mm 8.2mm x 5.0mm 10 0.39 24 26.2 0.95 1.03 30.5
20MS2TSPE2MSNK4 20 Halogen Free Polyamide Metric (Tru) M20 1.5 3 x 3mm 3 x 4mm 10 0.39 24 26.2 0.95 1.03 30.5
20FF2TSPE2TDN4 20 Halogen Free Polyamide Metric (Tru) M20 1.5 8mm x 4mm 10.3mm x 6.0mm 10 0.39 24 26.2 0.95 1.03 30.5
20DTSPE2TPN4 20D Halogen Free Polyamide Metric (Tru) M20 1.5 5 14 0.2 0.55 10 0.39 24 26.2 0.95 1.03 30.5
20MS1TSPE2MSNK4 20 Halogen Free Polyamide Metric (Tru) M20 1.5 2 x 3mm 2 x 5mm 10 0.39 24 26.2 0.95 1.03 30.5
20FF4TSPE2TDN4 20 Halogen Free Polyamide Metric (Tru) M20 1.5 11mm x 4mm 13.5mm x 7.0mm 10 0.39 24 26.2 0.95 1.03 30.5
20DTSPE2TDN4 20D Halogen Free Polyamide Metric (Tru) M20 1.5 5 14 0.2 0.55 10 0.39 24 26.2 0.95 1.03 30.5
20TSPE2TDN4 20 Halogen Free Polyamide Metric (Tru) M20 1.5 9 14 0.35 0.55 10 0.39 24 26.2 0.95 1.03 30.5
20DTSPE1TD4 20D Halogen Free Polyamide Metric (Tru) M20 1.5 5 14 0.2 0.55 10 0.39 24 26.2 0.95 1.03 30.5
20TSPE1TD4 20 Halogen Free Polyamide Metric (Tru) M20 1.5 9 14 0.35 0.55 10 0.39 24 26.2 0.95 1.03 30.5
25MS7TSPE2MSNK4T 25 Halogen Free Polyamide NPT 3/4" 4 x 4mm 4 x 6mm 15 0.59 30 32.7 1.18 1.29 36
25MS3TSPE2MSNK4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 2 x 5mm 2 x 8mm 10 0.39 30 32.7 1.18 1.29 36
25FF7TSPE2TDN4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 12.9mm x 5.9mm 15.9mm x 7.7mm 10 0.39 30 32.7 1.18 1.29 36
25FF6TSPE2TDN4T 25 Halogen Free Polyamide NPT 3/4" 12mm x 3.2mm 15.0mm x 5.0mm 15 0.59 30 32.7 1.18 1.29 36
25MS8TSPE2MSNK4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 5 x 2mm 5 x 4mm 10 0.39 30 32.7 1.18 1.29 36
25FF1TSPE2TDN4T 25 Halogen Free Polyamide NPT 3/4" 8mm x 4mm 10.3mm x 6.0mm 15 0.59 30 32.7 1.18 1.29 36
25MS1TSPE2MSNK4T 25 Halogen Free Polyamide NPT 3/4" 2 x 4mm 2 x 6mm 15 0.59 30 32.7 1.18 1.29 36
25MS6TSPE2MSNK4T 25 Halogen Free Polyamide NPT 3/4" 4 x 3mm 4 x 5mm 15 0.59 30 32.7 1.18 1.29 36
25MS2TSPE2MSNK4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 2 x 5mm 2 x 7mm 10 0.39 30 32.7 1.18 1.29 36
25DTSPE2TPN4T 25D Halogen Free Polyamide NPT 3/4" 9 18 0.35 0.71 15 0.59 30 32.7 1.18 1.29 36
25FF6TSPE2TDN4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 12mm x 3.2mm 15.0mm x 5.0mm 10 0.39 30 32.7 1.18 1.29 36
25FF2TSPE2TDN4T 25 Halogen Free Polyamide NPT 3/4" 9.4mm x 4.7mm 12.4mm x 6.5mm 15 0.59 30 32.7 1.18 1.29 36
25TSPE2TDN4T 25 Halogen Free Polyamide NPT 3/4" 12.5 18 0.49 0.71 15 0.59 30 32.7 1.18 1.29 36
25FF1TSPE2TDN4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 8mm x 4mm 10.3mm x 6.0mm 10 0.39 30 32.7 1.18 1.29 36
25MS7TSPE2MSNK4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 4 x 4mm 4 x 6mm 10 0.39 30 32.7 1.18 1.29 36
25FF5TSPE2TDN4T 25 Halogen Free Polyamide NPT 3/4" 10.8mm x 5.4mm 13.8mm x 7.2mm 15 0.59 30 32.7 1.18 1.29 36
25FF2TSPE2TDN4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 9.4mm x 4.7mm 12.4mm x 6.5mm 10 0.39 30 32.7 1.18 1.29 36
25MS10TSPE2MSNK4T 25 Halogen Free Polyamide NPT 3/4" 4 x 5mm 4 x 6.5mm 15 0.59 30 32.7 1.18 1.29 36
25MS1TSPE2MSNK4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 2 x 3mm 2 x 6mm 10 0.39 30 32.7 1.18 1.29 36
25FF5TSPE2TDN4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 10.8mm x 5.4mm 13.8mm x 7.2mm 10 0.39 30 32.7 1.18 1.29 36
25MS5TSPE2MSNK4T 25 Halogen Free Polyamide NPT 3/4" 3 x 5mm 3 x 7mm 15 0.59 30 32.7 1.18 1.29 36
25MS6TSPE2MSNK4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 4 x 3mm 4 x 5mm 10 0.39 30 32.7 1.18 1.29 36
25FF4TSPE2TDN4T 25 Halogen Free Polyamide NPT 3/4" 10.2mm x 3.4mm 13.2mm x 5.2mm 15 0.59 30 32.7 1.18 1.29 36
25TSPE1TD4T 25 Halogen Free Polyamide NPT 3/4" 12.5 18 0.49 0.71 15 0.59 30 32.7 1.18 1.29 36
25DTSPE2TDN4T 25D Halogen Free Polyamide NPT 3/4" 9 18 0.35 0.71 15 0.59 30 32.7 1.18 1.29 36
25TSPE2TDN4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 12.5 18 0.49 0.71 10 0.39 30 32.7 1.18 1.29 36
25MS10TSPE2MSNK4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 4 x 5mm 4 x 6.5mm 10 0.39 30 32.7 1.18 1.29 36
25FF4TSPE2TDN4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 10.2mm x 3.4mm 13.2mm x 5.2mm 10 0.39 30 32.7 1.18 1.29 36
25MS4TSPE2MSNK4T 25 Halogen Free Polyamide NPT 3/4" 3 x 4mm 3 x 6mm 15 0.59 30 32.7 1.18 1.29 36
25TSPE2TPN4T 25 Halogen Free Polyamide NPT 3/4" 12.5 18 0.49 0.71 15 0.59 30 32.7 1.18 1.29 36
25MS5TSPE2MSNK4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 3 x 5mm 3 x 7mm 10 0.39 30 32.7 1.18 1.29 36
25MS9TSPE2MSNK4T 25 Halogen Free Polyamide NPT 3/4" 5 x 3mm 5 x 5mm 15 0.59 30 32.7 1.18 1.29 36
25DTSPE1TD4T 25D Halogen Free Polyamide NPT 3/4" 9 18 0.35 0.71 15 0.59 30 32.7 1.18 1.29 36
25TSPE1TD4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 12.5 18 0.49 0.71 10 0.39 30 32.7 1.18 1.29 36
25FF8TSPE2TDN4T 25 Halogen Free Polyamide NPT 3/4" 7mm x 2.2mm 10.0mm x 4.0mm 15 0.59 30 32.7 1.18 1.29 36
25DTSPE2TDN4L 25D Halogen Free Polyamide Metric (Tru) M25 1.5 9 18 0.35 0.71 10 0.39 30 32.7 1.18 1.29 36
25MS3TSPE2MSNK4T 25 Halogen Free Polyamide NPT 3/4" 2 x 6mm 2 x 8mm 15 0.59 30 32.7 1.18 1.29 36
25MS4TSPE2MSNK4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 3 x 3mm 3 x 6mm 10 0.39 30 32.7 1.18 1.29 36
25FF8TSPE2TDN4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 7mm x 2.2mm 10.0mm x 4.0mm 10 0.39 30 32.7 1.18 1.29 36
25FF3TSPE2TDN4T 25 Halogen Free Polyamide NPT 3/4" 9.7mm x 7mm 12.4mm x 8.8mm 15 0.59 30 32.7 1.18 1.29 36
25MS8TSPE2MSNK4T 25 Halogen Free Polyamide NPT 3/4" 5 x 2mm 5 x 4mm 15 0.59 30 32.7 1.18 1.29 36
25MS9TSPE2MSNK4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 5 x 3mm 5 x 5mm 10 0.39 30 32.7 1.18 1.29 36
25FF7TSPE2TDN4T 25 Halogen Free Polyamide NPT 3/4" 12.9mm x 5.9mm 15.9mm x 7.7mm 15 0.59 30 32.7 1.18 1.29 36
25MS2TSPE2MSNK4T 25 Halogen Free Polyamide NPT 3/4" 2 x 5mm 2 x 7mm 15 0.59 30 32.7 1.18 1.29 36
25DTSPE1TD4L 25D Halogen Free Polyamide Metric (Tru) M25 1.5 9 18 0.35 0.71 10 0.39 30 32.7 1.18 1.29 36
25FF3TSPE2TDN4L 25 Halogen Free Polyamide Metric (Tru) M25 1.5 9.7mm x 7mm 12.4mm x 8.8mm 10 0.39 30 32.7 1.18 1.29 36
25MS1TSPE2MSNK4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 2 x 4mm 2 x 6mm 10 0.39 30 32.7 1.18 1.29 36
25TSPE2TPN4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 12.5 18 0.49 0.71 10 0.39 30 32.7 1.18 1.29 36
25FF6TSPE2TDN4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 12mm x 3.2mm 15.0mm x 5.0mm 10 0.39 30 32.7 1.18 1.29 36
25FF1TSPE2TDN4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 8mm x 4mm 10.3mm x 6.0mm 10 0.39 30 32.7 1.18 1.29 36
25MS7TSPE2MSNK4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 4 x 4mm 4 x 6mm 10 0.39 30 32.7 1.18 1.29 36
25MS10TSPE2MSNK4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 4 x 5mm 4 x 6.5mm 10 0.39 30 32.7 1.18 1.29 36
25FF2TSPE2TDN4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 9.4mm x 4.7mm 12.4mm x 6.5mm 10 0.39 30 32.7 1.18 1.29 36
25FF5TSPE2TDN4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 10.8mm x 5.4mm 13.8mm x 7.2mm 10 0.39 30 32.7 1.18 1.29 36
25MS6TSPE2MSNK4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 4 x 3mm 4 x 5mm 10 0.39 30 32.7 1.18 1.29 36
25TSPE2TDN4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 12.5 18 0.49 0.71 10 0.39 30 32.7 1.18 1.29 36
25DTSPE2TDN4 25D Halogen Free Polyamide Metric (Tru) M25 1.5 9 18 0.35 0.71 10 0.39 30 32.7 1.18 1.29 36
25FF4TSPE2TDN4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 10.2mm x 3.4mm 13.2mm x 5.2mm 10 0.39 30 32.7 1.18 1.29 36
25MS4TSPE2MSNK4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 3 x 4mm 3 x 6mm 10 0.39 30 32.7 1.18 1.29 36
25DTSPE2TPN4 25D Halogen Free Polyamide Metric (Tru) M25 1.5 9 18 0.35 0.71 10 0.39 30 32.7 1.18 1.29 36
25MS5TSPE2MSNK4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 3 x 5mm 3 x 7mm 10 0.39 30 32.7 1.18 1.29 36
25TSPE1TD4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 12.5 18 0.49 0.71 10 0.39 30 32.7 1.18 1.29 36
25DTSPE1TD4 25D Halogen Free Polyamide Metric (Tru) M25 1.5 9 18 0.35 0.71 10 0.39 30 32.7 1.18 1.29 36
25MS3TSPE2MSNK4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 2 x 6mm 2 x 8mm 10 0.39 30 32.7 1.18 1.29 36
25FF8TSPE2TDN4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 7mm x 2.2mm 10.0mm x 4.0mm 10 0.39 30 32.7 1.18 1.29 36
25MS9TSPE2MSNK4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 5 x 3mm 5 x 5mm 10 0.39 30 32.7 1.18 1.29 36
25MS2TSPE2MSNK4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 2 x 5mm 2 x 7mm 10 0.39 30 32.7 1.18 1.29 36
25FF3TSPE2TDN4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 9.7mm x 7mm 12.4mm x 8.8mm 10 0.39 30 32.7 1.18 1.29 36
25MS1TSPE1TD4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 2 x 4mm 2 x 6mm 10 0.39 30 32.7 1.18 1.29 36
25FF7TSPE2TDN4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 12.9mm x 5.9mm 15.9mm x 7.7mm 10 0.39 30 32.7 1.18 1.29 36
25MS2TSPE1TD4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 2 x 5mm 2 x 7mm 10 0.39 30 32.7 1.18 1.29 36
25MS8TSPE2MSNK4 25 Halogen Free Polyamide Metric (Tru) M25 1.5 5 x 2mm 5 x 4mm 10 0.39 30 32.7 1.18 1.29 36
32MS6TSPE2MSNK4L 32 Halogen Free Polyamide Metric (Tru) M32 1.5 8 x 2mm 8 x 4mm 12 0.47 40 43.6 1.58 1.72 41
32DTSPE2TPN4T 32D Halogen Free Polyamide NPT 1" 12.5 25 0.49 0.98 18 0.71 40 43.6 1.58 1.72 41
32DTSPE1TD4T 32D Halogen Free Polyamide NPT 1" 12.5 25 0.49 0.98 25 0.98 40 43.6 1.58 1.72 41
32FF1TSPE2TDN4L 32 Halogen Free Polyamide Metric (Tru) M32 1.5 14mm x 5mm 17.1mm x 10.0mm 12 0.47 40 43.6 1.58 1.72 41
32MS4TSPE2MSNK4T 32 Halogen Free Polyamide NPT 1" 4 x 6mm 4 x 8mm 25 0.98 40 43.6 1.58 1.72 41
32DTSPE2TDN4L 32D Halogen Free Polyamide Metric (Tru) M32 1.5 12.5 25 0.49 0.98 12 0.47 40 43.6 1.58 1.72 41
32MS5TSPE2MSNK4L 32 Halogen Free Polyamide Metric (Tru) M32 1.5 6 x 4mm 6 x 6mm 12 0.47 40 43.6 1.58 1.72 41
32TSPE2TDN4T 32 Halogen Free Polyamide NPT 1" 17 25 0.67 0.98 25 0.98 40 43.6 1.58 1.72 41
32MS3TSPE2MSNK4T 32 Halogen Free Polyamide NPT 1" 1 x 6mm 2 x 10mm 1 x 7.6 2 x 11.7mm 25 0.98 40 43.6 1.58 1.72 41
32DTSPE1TD4L 32D Halogen Free Polyamide Metric (Tru) M32 1.5 12.5 25 0.49 0.98 12 0.47 40 43.6 1.58 1.72 41
32TSPE1TD4T 32 Halogen Free Polyamide NPT 1" 17 25 0.67 0.98 25 0.98 40 43.6 1.58 1.72 41
32MS4TSPE2MSNK4L 32 Halogen Free Polyamide Metric (Tru) M32 1.5 4 x 5mm 4 x 8mm 12 0.47 40 43.6 1.58 1.72 41
32TSPE2TPN4T 32 Halogen Free Polyamide NPT 1" 17 25 0.67 0.98 18 0.71 40 43.6 1.58 1.72 41
32TSPE2TDN4L 32 Halogen Free Polyamide Metric (Tru) M32 1.5 17 25 0.67 0.98 12 0.47 40 43.6 1.58 1.72 41
32MS2TSPE2MSNK4T 32 Halogen Free Polyamide NPT 1" 1 x 5mm 2 x 8mm 1 x 6.8 2 x 10.2mm 25 0.98 40 43.6 1.58 1.72 41
32MS3TSPE2MSNK4L 32 Halogen Free Polyamide Metric (Tru) M32 1.5 2 x 9mm 1 x 5mm 2 x 11.7mm 1 x 7.6mm 12 0.47 40 43.6 1.58 1.72 41
32MS7TSPE2MSNK4T 32 Halogen Free Polyamide NPT 1" 8 x 4mm 8 x 5mm 25 0.98 40 43.6 1.58 1.72 41
32TSPE1TD4L 32 Halogen Free Polyamide Metric (Tru) M32 1.5 17 25 0.67 0.98 12 0.47 40 43.6 1.58 1.72 41
32MS1TSPE2MSNK4T 32 Halogen Free Polyamide NPT 1" 3 x 8mm 3 x 10.2mm 25 0.98 40 43.6 1.58 1.72 41
32MS2TSPE2MSNK4L 32 Halogen Free Polyamide Metric (Tru) M32 1.5 2 x 7mm 1 x 4mm 2 x 10.2mm 1 x 6.8mm 12 0.47 40 43.6 1.58 1.72 41
32MS6TSPE2MSNK4T 32 Halogen Free Polyamide NPT 1" 8 x 3mm 8 x 4mm 25 0.98 40 43.6 1.58 1.72 41
32MS7TSPE2MSNK4L 32 Halogen Free Polyamide Metric (Tru) M32 1.5 8 x 3mm 8 x 5mm 12 0.47 40 43.6 1.58 1.72 41
32DTSPE2TDN4T 32D Halogen Free Polyamide NPT 1" 12.5 25 0.49 0.98 25 0.98 40 43.6 1.58 1.72 41
32MS1TSPE2MSNK4L 32 Halogen Free Polyamide Metric (Tru) M32 1.5 3 x 6mm 3 x 10.2mm 12 0.47 40 43.6 1.58 1.72 41
32MS5TSPE2MSNK4T 32 Halogen Free Polyamide NPT 1" 6 x 4mm 6 x 6mm 25 0.98 40 43.6 1.58 1.72 41
32FF1TSPE2TDN4T 25 Halogen Free Polyamide NPT 1" 14mm x 5mm 17.1mm x 10.0mm 25 0.98 40 43.6 1.58 1.72 41
32DTSPE2TDN4 32D Halogen Free Polyamide Metric (Tru) M32 1.5 12.5 25 0.49 0.98 12 0.47 40 43.6 1.58 1.72 41
32MS5TSPE2MSNK4 32 Halogen Free Polyamide Metric (Tru) M32 1.5 6 x 4mm 6 x 6mm 12 0.47 40 43.6 1.58 1.72 41
32DTSPE1TD4 32D Halogen Free Polyamide Metric (Tru) M32 1.5 12.5 25 0.49 0.98 12 0.47 40 43.6 1.58 1.72 41
32MS4TSPE2MSNK4 32 Halogen Free Polyamide Metric (Tru) M32 1.5 4 x 6mm 4 x 8mm 12 0.47 40 43.6 1.58 1.72 41
32DTSPE2TPN4 32D Halogen Free Polyamide Metric (Tru) M32 1.5 12.5 25 0.49 0.98 12 0.47 40 43.6 1.58 1.72 41
32TSPE2TDN4 32 Halogen Free Polyamide Metric (Tru) M32 1.5 17 25 0.67 0.98 12 0.47 40 43.6 1.58 1.72 41
32MS3TSPE2MSNK4 32 Halogen Free Polyamide Metric (Tru) M32 1.5 1 x 6mm 2 x 10mm 1 x 7.6 2 x 11.7mm 12 0.47 40 43.6 1.58 1.72 41
32TSPE1TD4 32 Halogen Free Polyamide Metric (Tru) M32 1.5 17 25 0.67 0.98 12 0.47 40 43.6 1.58 1.72 41
32MS2TSPE2MSNK4 32 Halogen Free Polyamide Metric (Tru) M32 1.5 1 x 5mm 2 x 8mm 1 x 6.8 2 x 10.2mm 12 0.47 40 43.6 1.58 1.72 41
32MS1TSPE1TD4 32 Halogen Free Polyamide Metric (Tru) M32 1.5 3 x 8mm 3 x 10.2mm 12 0.47 40 43.6 1.58 1.72 41
32MS7TSPE2MSNK4 32 Halogen Free Polyamide Metric (Tru) M32 1.5 8 x 4mm 8 x 5mm 12 0.47 40 43.6 1.58 1.72 41
32MS2TSPE1TD4 32 Halogen Free Polyamide Metric (Tru) M32 1.5 1 x 5mm 2 x 8mm 1 x 6.8 2 x 10.2mm 12 0.47 40 43.6 1.58 1.72 41
32MS1TSPE2MSNK4 32 Halogen Free Polyamide Metric (Tru) M32 1.5 3 x 8mm 3 x 10.2mm 12 0.47 40 43.6 1.58 1.72 41
32MS6TSPE2MSNK4 32 Halogen Free Polyamide Metric (Tru) M32 1.5 8 x 3mm 8 x 4mm 12 0.47 40 43.6 1.58 1.72 41
32TSPE2TPN4 32 Halogen Free Polyamide Metric (Tru) M32 1.5 17 25 0.67 0.98 12 0.47 40 43.6 1.58 1.72 41
32FF1TSPE2TDN4 32 Halogen Free Polyamide Metric (Tru) M32 1.5 14mm x 5mm 17.1mm x 10.0mm 12 0.47 40 43.6 1.58 1.72 41
40DTSPE1TD4T 40D Halogen Free Polyamide NPT 1-1/4" 19 32 0.75 1.26 18 0.71 50 54.5 1.97 2.15 49
40DTSPE2TDN4L 40D Halogen Free Polyamide Metric (Tru) M40 1.5 19 32 0.75 1.26 12 0.47 50 54.5 1.97 2.15 49
40TSPE2TDN4T 40 Halogen Free Polyamide NPT 1-1/4" 24 32 0.94 1.26 18 0.71 50 54.5 1.97 2.15 49
40TSPE2TPN4T 40 Halogen Free Polyamide NPT 1-1/4" 24 32 0.94 1.26 18 0.71 50 54.5 1.97 2.15 49
40DTSPE1TD4L 40D Halogen Free Polyamide Metric (Tru) M40 1.5 19 32 0.75 1.26 12 0.47 50 54.5 1.97 2.15 49
40TSPE1TD4T 40 Halogen Free Polyamide NPT 1-1/4" 24 32 0.94 1.26 18 0.71 50 54.5 1.97 2.15 49
40TSPE2TDN4L 40 Halogen Free Polyamide Metric (Tru) M40 1.5 24 32 0.94 1.26 12 0.47 50 54.5 1.97 2.15 49
40MS2TSPE2MSNK4T 40 Halogen Free Polyamide NPT 1-1/4" 4 x 8mm 4 x 10mm 18 0.71 50 54.5 1.97 2.15 49
40TSPE1TD4L 40 Halogen Free Polyamide Metric (Tru) M40 1.5 24 32 0.94 1.26 12 0.47 50 54.5 1.97 2.15 49
40MS1TSPE2MSNK4T 40 Halogen Free Polyamide NPT 1-1/4" 1 x 8mm 2 x 10mm 1 x 10.2mm 2 x 11.7mm 18 0.71 50 54.5 1.97 2.15 49
40MS2TSPE2MSNK4L 40 Halogen Free Polyamide Metric (Tru) M40 1.5 4 x 7mm 4 x 10mm 12 0.47 50 54.5 1.97 2.15 49
40FF1TSPE2TDN4T 25 Halogen Free Polyamide NPT 1-1/4" 15mm x 6mm 19.4mm x 10.0mm 18 0.71 50 54.5 1.97 2.15 49
40DTSPE2TPN4T 40D Halogen Free Polyamide NPT 1-1/4" 19 32 0.75 1.26 18 0.71 50 54.5 1.97 2.15 49
40DTSPE2TDN4T 40D Halogen Free Polyamide NPT 1-1/4" 19 32 0.75 1.26 18 0.71 50 54.5 1.97 2.15 49
40MS1TSPE2MSNK4L 40 Halogen Free Polyamide Metric (Tru) M40 1.5 2 x 8mm 1 x 7mm 2 x 11.7mm 1 x 10.2mm 12 0.47 50 54.5 1.97 2.15 49
40FF1TSPE2TDN4L 40 Halogen Free Polyamide Metric (Tru) M40 1.5 15mm x 6mm 19.4mm x 10.0mm 12 0.47 50 54.5 1.97 2.15 49
40DTSPE1TD4 40D Halogen Free Polyamide Metric (Tru) M40 1.5 19 32 0.75 1.26 12 0.47 50 54.5 1.97 2.15 49
40DTSPE2TPN4 40D Halogen Free Polyamide Metric (Tru) M40 1.5 19 32 0.75 1.26 12 0.47 50 54.5 1.97 2.15 49
40TSPE2TDN4 40 Halogen Free Polyamide Metric (Tru) M40 1.5 24 32 0.94 1.26 12 0.47 50 54.5 1.97 2.15 49
40TSPE1TD4 40 Halogen Free Polyamide Metric (Tru) M40 1.5 24 32 0.94 1.26 12 0.47 50 54.5 1.97 2.15 49
40MS1TSPE1TD4 40 Halogen Free Polyamide Metric (Tru) M40 1.5 1 x 8mm 2 x 10mm 1 x 10.2mm 2 x 11.7mm 12 0.47 50 54.5 1.97 2.15 49
40MS2TSPE1TD4 40 Halogen Free Polyamide Metric (Tru) M40 1.5 4 x 8mm 4 x 10mm 12 0.47 50 54.5 1.97 2.15 49
40MS2TSPE2MSNK4 40 Halogen Free Polyamide Metric (Tru) M40 1.5 4 x 8mm 4 x 10mm 12 0.47 50 54.5 1.97 2.15 49
40TSPE2TPN4 40 Halogen Free Polyamide Metric (Tru) M40 1.5 24 32 0.94 1.26 12 0.47 50 54.5 1.97 2.15 49
40MS1TSPE2MSNK4 40 Halogen Free Polyamide Metric (Tru) M40 1.5 1 x 8mm 2 x 10mm 1 x 10.2mm 2 x 11.7mm 12 0.47 50 54.5 1.97 2.15 49
40FF1TSPE2TDN4 40 Halogen Free Polyamide Metric (Tru) M40 1.5 15mm x 6mm 19.4mm x 10.0mm 12 0.47 50 54.5 1.97 2.15 49
40DTSPE2TDN4 40D Halogen Free Polyamide Metric (Tru) M40 1.5 19 32 0.75 1.26 12 0.47 50 54.5 1.97 2.15 49
50TSPE2TPN4T 50 Halogen Free Polyamide NPT 1-1/2" 28 38 1.1 1.5 19 0.75 58 63.2 2.29 2.49 59
50DTSPE1TD4L 50D Halogen Free Polyamide Metric (Tru) M50 1.5 22 38 0.87 1.5 12 0.47 58 63.2 2.29 2.49 59
50TSPE2TDN4T 50 Halogen Free Polyamide NPT 1-1/2" 28 38 1.1 1.5 19 0.75 58 63.2 2.29 2.49 59
50TSPE1TD4T 50 Halogen Free Polyamide NPT 1-1/2" 28 38 1.1 1.5 19 0.75 58 63.2 2.29 2.49 59
50TSPE2TDN4L 50 Halogen Free Polyamide Metric (Tru) M50 1.5 28 38 1.1 1.5 12 0.47 58 63.2 2.29 2.49 59
50DTSPE2TPN4T 50D Halogen Free Polyamide NPT 1-1/2" 22 38 0.87 1.5 19 0.75 58 63.2 2.29 2.49 59
50DTSPE2TDN4T 50D Halogen Free Polyamide NPT 1-1/2" 28 38 1.1 1.5 19 0.75 58 63.2 2.29 2.49 59
50TSPE1TD4L 50 Halogen Free Polyamide Metric (Tru) M50 1.5 28 38 1.1 1.5 12 0.47 58 63.2 2.29 2.49 59
50DTSPE1TD4T 50D Halogen Free Polyamide NPT 1-1/2" 28 38 1.1 1.5 19 0.75 58 63.2 2.29 2.49 59
50DTSPE2TDN4L 50D Halogen Free Polyamide Metric (Tru) M50 1.5 22 38 0.87 1.5 12 0.47 58 63.2 2.29 2.49 59
50DTSPE1TD4 50D Halogen Free Polyamide Metric (Tru) M50 1.5 22 38 0.87 1.5 12 0.47 58 63.2 2.29 2.49 59
50TSPE2TDN4 50 Halogen Free Polyamide Metric (Tru) M50 1.5 28 38 1.1 1.5 12 0.47 58 63.2 2.29 2.49 59
50TSPE2TPN4 50 Halogen Free Polyamide Metric (Tru) M50 1.5 28 38 1.1 1.5 12 0.47 58 63.2 2.29 2.49 59
50TSPE1TD4 50 Halogen Free Polyamide Metric (Tru) M50 1.5 28 38 1.1 1.5 12 0.47 58 63.2 2.29 2.49 59
50DTSPE2TDN4 50D Halogen Free Polyamide Metric (Tru) M50 1.5 22 38 0.87 1.5 12 0.47 58 63.2 2.29 2.49 59
50DTSPE2TPN4 50D Halogen Free Polyamide Metric (Tru) M50 1.5 22 38 0.87 1.5 12 0.47 58 63.2 2.29 2.49 59
63TSPE1TD4L 63 Halogen Free Polyamide Metric (Tru) M63 1.5 37 48 1.46 1.89 15 0.59 68 74.1 2.68 2.92 64
63DTSPE1TD4T 63D Halogen Free Polyamide NPT 2" 37 48 1.46 1.89 20 0.79 68 74.1 2.68 2.92 64
63DTSPE2TDN4L 63D Halogen Free Polyamide Metric (Tru) M63 1.5 28 48 1.1 1.89 15 0.59 68 74.1 2.68 2.92 64
63DTSPE1TD4L 63D Halogen Free Polyamide Metric (Tru) M63 1.5 28 48 1.1 1.89 15 0.59 68 74.1 2.68 2.92 64
63DTSPE2TPN4T 63D Halogen Free Polyamide NPT 2" 28 48 1.1 1.89 20 0.79 68 74.1 2.68 2.92 64
63TSPE2TDN4T 63 Halogen Free Polyamide NPT 2" 37 48 1.46 1.89 20 0.79 68 74.1 2.68 2.92 64
63TSPE1TD4T 63 Halogen Free Polyamide NPT 2" 37 48 1.46 1.89 20 0.79 68 74.1 2.68 2.92 64
63TSPE2TPN4T 63 Halogen Free Polyamide NPT 2" 37 48 1.46 1.89 20 0.79 68 74.1 2.68 2.92 64
63TSPE2TDN4L 63 Halogen Free Polyamide Metric (Tru) M63 1.5 37 48 1.46 1.89 15 0.59 68 74.1 2.68 2.92 64
63DTSPE2TDN4T 63D Halogen Free Polyamide NPT 2" 37 48 1.46 1.89 20 0.79 68 74.1 2.68 2.92 64
63DTSPE2TDN4 63D Halogen Free Polyamide Metric (Tru) M63 1.5 28 48 1.1 1.89 15 0.59 68 74.1 2.68 2.92 64
63DTSPE1TD4 63D Halogen Free Polyamide Metric (Tru) M63 1.5 28 48 1.1 1.89 15 0.59 68 74.1 2.68 2.92 64
63TSPE2TPN4 63 Halogen Free Polyamide Metric (Tru) M63 1.5 37 48 1.46 1.89 15 0.59 68 74.1 2.68 2.92 64
63TSPE2TDN4 63 Halogen Free Polyamide Metric (Tru) M63 1.5 37 48 1.46 1.89 15 0.59 68 74.1 2.68 2.92 64
63DTSPE2TPN4 63D Halogen Free Polyamide Metric (Tru) M63 1.5 28 48 1.1 1.89 15 0.59 68 74.1 2.68 2.92 64
63TSPE1TD4 63 Halogen Free Polyamide Metric (Tru) M63 1.5 37 48 1.46 1.89 15 0.59 68 74.1 2.68 2.92 64
1
No results

0 of 250 Selected

Your Shortlist

    Your Selection

      "*" indicates required fields

      We'd like to keep in touch

      We have some exciting things in the pipeline - if you'd like to be the first to know please enter your email address below.

      No thanks, I'd just like to Download the datasheets
